Features

• Proven impact drive with straight-through flow for superior performance in dirty water.
• Five standard trajectory and two low angle color-coded nozzles for matched precipitation and in a wide range of applications.
• 360° full-circle OR arc adjustable from 20° to 340°.
• Side and combination ½” or ¾” bottom inlet for design flexibility.

Specs

Precipitation Rate: 0.28 to 1.21 inches per hour (7 to 31 mm/h).
Radius: 22 to 45 feet (6,7 to 13,7 m).
Radius with Radius Reduction Screw: 18 ft (5,4 m).
Pressure: 25 to 60 psi (1,7 to 4,1 Bars).
Flow: 1.5 to 8.4 GPM (0,34 to 1,91 m³/h; 0,9 to 0,53 l/s).
Connection: 1/2″ (15/21) or 3/4″ (20/27) FPT bottom inlet  1/2″ (15/21) FPT side inlet.
Nozzles: 08-blue.
